Sample Valve GN

GN : Simple sample valve to take oil sample in an easy and fast way. Allways same lubricant sample in same place.

Carfully select sample valve installation !! Available in different metric and imperail sizes.

Features and applications

Oil drain valves GN 880 may be used for draining non-pressurised oil, as well conditionally

as for vacuum drainage.

The flow volume (l/min.) depends on the viscosity of the medium, the filling quantity and the

temperature. Guidance values available on request.

Other features are:

- easy and safe handling

- optimum flow rate

- high pressure resistance (up to 100 bar)

- high temperature resistance (-30°C to +120°C short period up to 180° C)

- 100 % seal-tight tested

- TÜV and DLG tested
